Slim Size Non-Dimmable LED Driver 150W (IP20)
SMT-012-150VWSP
Non-dimmable LED Driver
SMARTS
Model SMT-024-150VWSP slim waterproof constant voltage 24v led transformer power supply 150w, Passed ul certification, Can well protect the life of 150w led downlight square
model
SMT-012-150VW...
Model SMT-024-150VWSP slim waterproof constant voltage 24v led transformer power supply 150w, Passed ul certification, Can well protect the life of 150w led downlight square
| model | SMT-012-150VWSP | SMT-024-150VWSP | SMT-036-150VWSP | SMT-048-150VWSP | |
| Output | DC Voltage | 12VDC | 24VDC | 36VDC | 48VDC |
| Voltage Accuracy | ±5% | ||||
| Rated current | 12.5Amp | 6.25Amp | 4.16A | 3.125A | |
| Rated power | 150W | ||||
| Voltage Tolerance | ±0.5V | ||||
| Voltage Regulation | ±0.5% | ||||
| Load Regulation | ±1% | ||||
| Input | Voltage Range | 100-277 VAC | |||
| Frequency Range | 47~63HZ | ||||
| Power Factor ( Typ.) | 0.99@120VAC; 0.98@230VAC; 0.95@277VAC | ||||
| THD(Typ.)@ full load | <15%@120VAC <20%@230VAC <20%@277VAC | ||||
| Full Load Efficiency(Typ.) | 83%@120VAC; 85%@230VAC; 85%@ 277VAC | ||||
| AC Current(Typ.) | 1.4A/100VAC / 0.82A/230VAC / 0.43A/277VAC | ||||
| Inrush Current(Typ.) | 7A, 50%, 420us @120VAC ; 30A,50% 90us@230VAC; 12A,50%480us@277VAC | ||||
| Leakage current | <0.50mA | ||||
| Protection | Short Circuit | Hiccup mode, recovers automatically after fault condition is removed. | |||
| Over Loading | ≤120% shut down o/p voltage, re-power on to recover | ||||
| Over temperature | 100℃±10℃ shut down o/p voltage, automatically recover after cooling. | ||||
| Environment | Working TEMP. | -40~+60℃ | |||
| Working Humidity | 20~90%RH,non-condensing | ||||
| Storage TEM.,Humidity | -40~+80℃,10~95%RH | ||||
| TEMP.coefficient | ±0.03%/℃(0~50℃) | ||||
| Vibration | 10~500Hz,2G 10min./1 cycle,period for 60min.each along X,Y,Z axes | ||||
| Safety&EMC | Safety standards | EN61347-1 EN61347-2-13 | |||
| Withstand voltage | I/P-O/P: 3.75KVAC | ||||
| Isolation resistance | I/P-O/P:100M Ohms/500VDC/25℃/70%RH | ||||
| EMC EMISSION | Compliance to EN55015,EN61000-3-2 (≥60%load) | ||||
| EMC IMMUNITY | Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry | ||||
| Others | Weight | 0.40Kg | |||
| Size | 330*30*22mm (L*W*H) | ||||
| packing | 50PCS/CTN | ||||
| Notes | 1. All parameters NOT specially mentioned are measured at 110VAC, 220VAC, 277VAC input ,Rated load and 25℃of ambient temperature. | ||||
| 2. Tolerance:includes set us tolerance,line regulation and load regulation . | |||||
| 3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation,the final equipment manufactures must be-qualify EMC Directive on the complete installation again. | |||||
